ACOUSTICPRO UHD - SAMPLE SCREEN (DIN A4)



The AcousticPro UHD (ultra-high definition) is a moiré-free self-supported acoustically transparent front projection screen material. The dense synthetic perforated weave is compatible with Ultra-High Definition/4K resolutions while mitigating light penetration for a brighter picture. The AcousticPro UHD design maximizes sound penetration with minimal attenuation without compromising picture quality. The AcousticPro UHD material’s wide diffusion uniformity offers a broad viewing angle with superb picture quality across the entire surface.This provides equal brightness levels on or off axis.

“Speaking of “observing”, the Electric125H-AUHD performed admirably across a diversity of content and at all hours of day and night; its ambient light suppression was top-notch.” – Brian Dipert, EDN Network



Elite Screens Series:

Spectrum, Saker Tension, Evanesce, VMAX Dual, and Aeon Series





Projection Screens' material

Gain: 1.0

Viewing Angle: 180° (90°L/R)

Moiré-free perforated weave acoustically transparent material

Wide diffusion uniformity – maintains luminance levels throughout entire surface

Mildew Resistant

4K UHD, Active 3D, and HDR ready

Mean Attenuation: -2.36dB

ISF Certified for accurate color reproduction

Flame Retardant: Complies with NFPA 701 Standards







Tabular Response at 0° Angle of Incidence

Avg. Gain dB	Min. Gain dB	Max. Gain dB	Band
-1.5	-1.7	-1.4	100Hz- 500Hz
-1.7	-1.8	-1.6	500Hz- 1000Hz
-2.3	-3.4	-1.8	1000Hz- 10000Hz
-4.0	-4.6	-3.4	10000Hz- 18000Hz



Tabular Response at +/- 15 ° Angle of Incidence

Angle	Min. Variation (dB)	Max. Variation (dB)	Band
Horizontal +/-1.5°	-0.5	-1.7	100Hz- 1000Hz
Horizontal +/-1.5°	-0.4	-2.2	10000Hz- 18000Hz
Vertical +/-1.5°	-0.1	-1.4	10Hz- 10000Hz
Vertical +/-1.5°	-0.2	-3.0	10000Hz- 18000Hz

Lexicon:

Gain=Gain or Gainfactor is a measure of the screen reflection performance.

UHD= Ultra High Definition is the new standard for high-definition video. Under the term UHD Premium the topic is marketed and is also often referred to as 4K.

 4K: 4K stands for the doubling of Full HD 2K and designated in the marketing long longer the high-definition television and beamer. That's why there are also 4K screens on Elite Screens.

Aktiv 3D = Active 3D involves a single projector rapidly alternating between displaying the left eye image and the right eye image.

NFPA = National Fire Protection Association

HDR = High Dynamic Range, a Feature of the new UHD Premium Blu Ray Standard
